Cube Reaction Hybrid ONE 800 silver n black
Telaio: Alluminio Superlite, tecnologia Gravity Casting, controllo efficiente del comfort, FSP 4-Link, geometria Agile Comfort, Boost 148, UDH™, batteria completamente integrata, passaggio cavi interno avanzato, punti di montaggio per cavalletto/parafango/portapacchi, morsetto reggisella integrato
Materiale del telaio: alluminio
Dimensioni delle ruote: Divisione taglie: 27,5: S // 29: ML XL
Velocità: 1 x 10
Colore: notte e cromo
Forchetta: SR Suntour XCR34X 2CR Air, conico, 15x110mm, 120mm
Ammortizzatore posteriore: SR Suntour EdgeX R 185x52,5mm, regolazione del ritorno, montaggio Trunnion
Viaggio: 120 millimetri
Freni: Magura MT Thirty, freno a disco idraulico anteriore a 4 pistoncini/posteriore a 4 pistoncini
Dischi freno: 203/203 millimetri
Auricolare: ACROS AZF-1035, ICR (instradamento cavi integrato), BlockLock 120°, Zero-Stack superiore 1 1/2" (ZS 56 mm), Zero-Stack inferiore 1 1/2" (ZS 56 mm)
Stelo: Attacco manubrio CUBE Performance E-MTB 35, FPI-Link
Manubrio: Manubrio CUBE Rise Trail 35
Impugnature della barra: Esecuzione ibrida ACID
Sella: Sequenza ACID Pro 160
Reggisella: Reggisella telescopico CUBE, leva manubrio, passaggio cavi interno, 31,6 mm
Guarnitura: ACID MTB Hybrid Pro, 38T
Deragliatore posteriore: Shimano Cues RD-U6000-GS, 10 velocità
Leve del cambio: Stecche Shimano SL-U6000, Rapidfire-Plus
Guida catena: Guida per catena portacavi con guida a ribaltamento inversa, montaggio diretto, piastra a I
Cassetta: Stecche Shimano CS-LG300, 11-48T
Catena: KMC eGlide
Pneumatici: Schwalbe Smart Sam, Attivo, 2.6
Mozzo anteriore: CUBE Engineered By Newmen, 15 mm, Boost, 6 bulloni
Mozzo posteriore: CUBE Engineered By Newmen, 12 mm, Boost, 6 bulloni
Cerchi: CUBE EX30, 32H, Disco, Tubeless Ready
Display: Bosch Purion 200 con display integrato
Batteria: Bosch PowerTube 600
Caricabatterie: Bosch 2A
Motore: Unità di trasmissione Bosch Performance Line CX 85Nm Gen.5, (BDU38), sistema intelligente
Dimensioni del cuscinetto: Superiore: montaggio a perno da 54 mm, inferiore: 22,2x8 mm
Pedali: ACIDO PP MTB
Peso totale massimo consentito: 120 kg (peso corporeo + bici + attrezzatura)
Peso: a partire da 25,5 kg
Trasmissione
Motore del prodotto ... altro
Indietro
Trasmissione
Perché dovrei acquistare una e-bike con il sistema intelligente Bosch?
La tua e-bike continua a evolversi.
Anche dopo l'acquisto, è possibile aggiungere nuove funzioni tramite un aggiornamento "over-the-air", così il divertimento di guida è sempre garantito.
La tua e-bike è connessa
Grazie all'app eBike Flow, la tua e-bike è connessa al tuo smartphone e quindi anche al mondo digitale! L'app può essere collegata al LED Remote tramite Bluetooth e puoi aumentare il piacere di guida grazie a funzioni intelligenti e personalizzabili.
La tua e-bike dura più a lungo
Grazie alla capacità di 600 Wh, puoi continuare a pedalare anche quando gli altri sono a corto di energia. Goditi semplicemente l'autonomia aumentata e divertiti su lunghi tour e numerosi sentieri.
La tua e-bike ha un aspetto davvero bello
Ogni singolo componente del sistema intelligente Bosch può essere integrato in modo impeccabile e garantisce un design moderno e purista.
La tua e-bike trae vantaggio da un'interazione perfetta
Tutti i componenti del sistema intelligente sono coordinati e si armonizzano perfettamente, tra loro e con te. Grazie all'accesso al mondo digitale, puoi registrare e valutare automaticamente le tue attività e sincronizzarle con le tue app preferite.
Di quali componenti è composto il sistema intelligente Bosch?
Motore Bosch Drive Unit Performance Line CX Generation 5
Il motore Performance Line CX Gen.5 (BDU384Y) porta la dinamica di guida e l'agilità a un nuovo livello. È potente, leggero e silenzioso. Dieci anni di esperienza e innumerevoli percorsi in tutto il mondo sono stati impiegati per il suo ulteriore sviluppo. Il motore Performance Line CX combina potenza, dinamica, efficienza e portata. 85-600-340: 85 Nm di coppia massima, 600 W di potenza massima, fattore di supporto massimo del 340%. Questi valori rappresentano l'equilibrio ideale tra prestazioni e piacere di guida in relazione a usura e autonomia.
Potente in salita
La coppia massima di 85 Nm ha un impatto notevole sulle prestazioni di guida in eMountain bike. Il potente motore consente un'accelerazione potente dopo curve strette e ostacoli a bassa cadenza e semplifica le partenze in salita. Per gli sprint veloci, il motore ti supporta anche a cadenze elevate.
Intuitive handling
One mode for more focus: The eMTB mode, specially designed for sporty use, gives you optimum control and intuitive handling, as you don't have to switch between the different riding modes as often. With this clever eMTB mode function, technical passages can be ridden with confidence and obstacles such as roots and thick branches can be easily overcome with targeted pedal pressure using the Extended Boost. The Performance Line CX drive unit ensures even more riding fun and a flow experience that sets new standards.
Maximum agility
The multi-sensor concept enables controlled and agile riding even on technically demanding trails, combined with the innovative Bosch motor control, it stands for maximum dynamics and sensitivity.
Sporty and economical
Sporty riding on a trekking bike or eMTB: With the Tour+ riding mode of the Bosch Performance Line CX, the focus is always on riding enjoyment. It eliminates the need to switch between support modes so that you can concentrate fully on eBiking. With Tour+ mode, you pedal harder on flat stretches than in Tour mode and are more sporty on the road - the riding mode therefore saves power and extends your radius - for even more riding fun! Trail or asphalt - Tour+ mode always suits you. Because it constantly adapts to you. Sensors on the motor measure important riding data more than 1,000 times per second, from which the Tour+ mode derives the optimum support for you. It regulates the additional power so sensitively that you not only get a natural riding experience, but also a greater range with greater power input.
Individual riding experience
The available riding modes can be individually set in the eBike Flow app so that the eBike's riding characteristics match your own riding style or the route you have chosen. The level of assistance, dynamics, maximum speed and maximum torque of the drive can thus be flexibly adjusted to your personal needs and requirements. Intensive training or an extended eBike tour - the riding modes always offer you the right support and enable even more riding enjoyment.
The Performance Line CX responds to your input more sensitively than ever before
Bosch has reinterpreted and improved the signals from the sensors. Inertial sensors (IMU), cadence sensor, torque sensor. The new motor does exactly what you want - sensitive, controlled and direct. That's a natural riding experience
eMTB mode and Extended Boost
You don't need any other riding mode to get into the uphill flow. Because that's what Bosch has developed it for. The eMTB mode reacts progressively to you and recognizes in a flash how much power you want based on your pedal pressure - dynamically, with maximum traction and always in control. With the integrated Extended Boost, all it takes is a targeted kick on the pedal and the Drive Unit pushes you effortlessly over steps and stones.
Push assist and hill start assist
Get to your destination: Helpful functions take the weight off your eMTB when you need to stop in tricky sections. With the push assist, you can easily push your eMTB, while the Drive Unit automatically adjusts the pushing speed to the gradient and surface. In addition, the hill start assist enables a controlled and high-traction start, even on steep terrain. Hill Hold is active in both cases: your eMTB stays in place and does not roll back unexpectedly.
Compatible with Bosch eBike ABS Pro
Triumph over the trail: Bosch has developed the eBike Pro for outstanding performance. ABS Pro is ideal for professional eBikers: designed for fast, sporty downhill riding and braking. You can make full use of your braking skills and still feel how the system increases performance.
Compatible with eShift from TRP
Thanks to the electric shifting solution, you can ride to the trail with maximum relaxation and maximum performance on the trail. You can decide whether eShift with TRP should shift automatically for you or whether you want to change gear yourself on varied terrain with fast maneuvers - simply at the touch of a button. With eShift, gear changes are efficient and precise.
Optional PowerMore 250 range extender
Extend the range and enjoy even longer trail fun with the water bottle-sized energy reserve. Compact and 1.5 kilograms in weight, the range extender can be easily attached to the water bottle holder. It can be combined with all batteries in the smart system. Please find out in advance whether you can use the range extender for your eBike.
Individual riding modes
A natural riding experience is individual - with the eBike Flow app, you can create a riding mode to suit your needs. Your trail, your riding experience, your mode: With the help of four parameters, you can easily adapt the riding modes to your needs using the slider in the eBike Flow app. Support, dynamics, maximum torque and maximum speed - you decide what you need.
Powder-coated. Robust right up to the tips
The housing is made of magnesium - robust, corrosion-resistant and hard
The sealing concept prevents splash water from penetrating
The sound of the trail - nothing else: Bosch has been able to reduce the noise generated by the gearbox. The new motor is quiet. It creates a balance between power delivery and noise development
Power. Distributed over 2.8 kilograms. The Performance Line CX is around 100 grams lighter than the previous version
Bosch eBike Flow app
Extend the eBike
Use the eBike Flow app to download new functions and updates for components such as the battery or motor and send them to your eBike via Bluetooth. This keeps it up to date and gives you more options.
Record activities
Record your tour and fitness data as soon as you set off. For iPhone users, Activity Tracking also synchronizes all data automatically with Apple Health if desired. If you take a break, the recording stops automatically.
Individualize riding modes
Customize the riding mode exactly to your needs: You can fine-tune the Eco, Tour, Sport and Turbo riding modes so that they offer you more support or consume less power.
Keep an eye on everything
Get a quick overview of everything important on the home screen. Whether battery status, remaining range, distance already ridden or next service appointment - the home screen shows you everything you need to know with constantly updated eBike data.
Bosch Purion 200 Remote with integrated 1.6" color display
Developed with ergonomics experts
Purion 200 is mounted on the left-hand side of the handlebar, close to the thumb. Thanks to its curved shape, the combination of control unit and display fits beautifully on the handlebars. If the plus and minus buttons are aligned correctly - i.e. almost vertically - this means more comfort for you when operating the system and faster reading of the riding data. You can control your eBike with just one thumb movement and change the riding mode or the display, for example. We developed Purion 200 together with the ergonomics experts from SQlab to achieve the optimum combination of functionality, comfort and design.
Optimum readability
A high resolution, greater color depth, a clear structure and easy-to-understand symbols ensure that you can quickly read and understand the information on Purion 200. The integrated ambient light sensor automatically adjusts the brightness of the display depending on the ambient light. This makes it very easy to read even in sunshine and darkness.
Powerful display combinations
If you want more information or a larger display for even better readability, you can use another display in addition to Purion 200: Have Kiox 300 or Kiox 500 fitted by a specialist dealer or use your smartphone as a second display using SmartphoneGrip and the eBike Flow app. The additional new main display is controlled via the Purion 200 buttons. Purion 200 continues to show you the information that was last selected: For example, you can display the current speed on Purion 200 while your main display navigates you.
Ampia gamma di funzioni
Purion 200 offre numerose funzioni per aiutarti a pedalare e arrivare meglio. Oltre alle funzioni di base come l'accensione e lo spegnimento dell'eBike e delle luci, puoi anche attivare la funzione di assistenza alla spinta intelligente tramite i pulsanti di Purion 200, ad esempio, per facilitare la spinta dell'eBike mentre cammini. Con la semplice pressione di un pulsante, puoi cambiare il display in pochi secondi e selezionare semplicemente le informazioni che ti interessano al momento: ad esempio, tieni d'occhio l'autonomia residua, vedi quanta strada hai già percorso o controlla la tua cadenza.
Connessa in modo intelligente
Cinque pulsanti, un display e tante opzioni: Purion 200 è in rete nel sistema intelligente e collega l'eBike all'app eBike Flow. Questo ti offre funzioni digitali che puoi facilmente attivare e utilizzare tramite l'app, ad esempio per una maggiore protezione antifurto, la registrazione delle tue attività o la possibilità di adattare le modalità di guida alle tue esigenze. Inoltre, Purion 200 è l'interfaccia per trasferire gli aggiornamenti alla tua eBike. Così rimane sempre aggiornata.
Bosch PowerTube 600 / 800
Massima portata
Con PowerTube 600/800 è possibile superare facilmente lunghe distanze e molti metri di altitudine.
Design elegante per eBike
Come tutte le Bosch PowerTube, anche la PowerTube 600/800 è perfettamente integrata nel telaio. Design accattivante per eBike e capacità elevata: una combinazione senza compromessi. Per la batteria è stato utilizzato un nuovo alloggiamento più leggero. Se il produttore dell'eBike ha predisposto l'eBike per questo scopo, la batteria può essere facilmente sostituita, per ottenere un'autonomia maggiore o minore.
Fornitore di energia affidabile
Elevati standard di sicurezza. Enorme autonomia, lunga durata, maneggevolezza affidabile: la batteria agli ioni di litio è dotata di un sistema di gestione della batteria che protegge le celle della batteria dal sovraccarico.
Utilizzo intuitivo
La PowerTube 600 / 800 si distingue per la sua particolare maneggevolezza. La batteria è sempre saldamente ancorata al telaio in tutti i tour, la rimozione avviene tramite un meccanismo intuitivo e bloccabile, offrendo un utilizzo intuitivo.
Tabella comparativa
PowerTube 600 800
Sistema Il sistema intelligente Il sistema intelligente
Tipo di montaggio Nella cornice Nella cornice:
Orizzontale / Verticale
Voltaggio 36 Volt 36 Volt
Capacità della batteria 16,7 Ah 22,2 Ah
Contenuto energetico circa 600 Wh circa 800 Wh
Peso 25 KG
